The product has a flange at one end and a bellmouth at the other end. Compared with the traditional expansion piece, the product is light in weight, excellent in performance, novel in structure, simple in installation, and good in sealing effect.
It can replace the expansion piece, flange plate, short pipe A, short pipe B, pipe clamp, etc. It can be quickly connected with valves, water meters and pipeline components.
As a kind of compensator, metal bellows compensator is made of austenitic stainless steel or the material required by users, with good flexibility, corrosion resistance, high-temperature resistance (-235℃ - +450℃) and high-pressure resistance (the maximum pressure is 32MPa).
Metal bellows is a kind of regular wavy pipe. Common metal bellows may be made of carbon steel, stainless steel, steel lining plastic, aluminum, etc.
It consists of rubber parts reinforced by fabric or other materials and components such as parallel movable joints or metal flanges, which is used for shock absorption, vibration isolation, noise reduction and displacement compensation of pipeline system.
It is composed of flange lapped compensating joint, short pipe flange, force transmission screw and other components. It transmits the pressure thrust of the connected parts and compensates the installation error of the pipeline.
It is composed of flange lapped compensating joint, short pipe flange, force transmission screw and other components. It transmits the pressure thrust of the connected parts and compensates the installation error of the pipeline.
It is composed of flange lapped compensating joint, short pipe flange, force transmission screw and other components. It transmits the pressure thrust of the connected parts and compensates the installation error of the pipeline.
It consists of lapped compensating joint and limit expansion pipe, to prevent the leakage or damage of the compensating joint due to excessive displacement. It is a device of lapped joint of pipeline which is used to absorb axial displacement and withstand pressure thrust within the allowable displacement range.
The device of lapped connecting pipe consists of a body, a seal ring and a compression member, which is used for absorbing the axial displacement and cannot withstand the pressure thrust.
