Product overview
Y-type filter is an indispensable filter device for medium transporting pipeline system. Y-type filter is usually installed at the inlet end of pressure reducing valve, pressure relief valve, fixed water level valve or other equipment to remove impurities in the medium, to protect the normal use of valves and equipment. Y-type filter has characteristics such as advanced structure, small resistance and convenient pollution discharge. The suitable media for Y-type filter are water, oil and gas. Generally, the water screen is 18-30 mesh, the air screen is 10-100 mesh, and the oil screen is 100-480 mesh. The basket filter mainly consists of connecting pipe, main pipe, filter basket, flange, flange cover and fastener. When the liquid enters the filter basket through the main pipe, solid impurities and particles are blocked in the filter basket, and the clean fluid passes through the filter basket and is discharged from the filter outlet.
Technical requirements
1.Connection dimension basis: DIN EN558-1
2.Flange drilling basis: DIN EN1092-2
3.Working pressure: PN10-PN16
