Product characteristics
The manufacturing process of cylindrical valve body structure is simple, which is convenient for assembly and positioning. The mold needed for manufacturing the blank is simple and it is convenient to fix the ball with the support plate.
1.Domestic leading technology, maintenance-free, long service life.
2.Unique welding process, without pore and sand hole, high pressure-bearing, no leakage of valve body.
3.Adopt high-quality stainless steel ball, double layer support seal structure, and scientific and reasonable ball support. 4.The gasket is made of Teflon, nickel, graphite and other materials, and is carbonized.
5.The valve well has low cost and can be conveniently opened and operated.
6.The valve body length of the directly-buried welded ball valve can be determined according to the buried depth.
7.It is equipped with a grease injection port of check valve type which can prevent the backflow of the lubricating sealant under high pressure.
8.According to the needs of medium of the pipeline system, the valve is equipped with the device for releasing, discharging and preventing.
9.CNC production equipment, strong technical support, reasonable hardware and software collocation.
